Model |
FK2528MP20 |
|
Image Size |
1.1-inch |
|
Focal length |
25mm |
|
F No. |
F2.8-22 |
|
M.O.D(m) |
0.15-Inf. |
|
Operation |
Iris |
Manual |
Focus |
Manual |
|
Horizontal Angle of View |
1.1" Type |
39.5°×31.6°×23.6° |
1"Type |
36.2°×29.1°×21.9° |
|
1/2"Type |
18.5°×14.7°×11.1° |
|
1/3"Type |
13.8°×11.1°×8.3° |
|
Distortion |
-0.59%@y=8.8㎜;-0.12%@y=4㎜ |
|
Flange BFL |
17.526mm |
|
Back focal length |
12.6mm |
|
Mount |
C-Mount |
|
1.1"FOV |
81.4mm×61.1mm(WD=150mm) |
|
Dimension |
Ф33x36.5mm |
|
Weight |
93.5g |
|
Filter Thread |
M30.5x 0.5mm |
|
Working Temperature |
-20ºC ~ +60ºC |
